Linde Diesel Forklift Truck H1283 Series: HT25Ds, HT30Ds Service Training (Workshop) Manual

Original Illustrated Factory Service Training (Workshop) Manual for Linde Diesel Forklift Truck H-Series Type 1283.

Original factory manuals for Linde Forklift Trucks, contains high quality images, circuit diagrams and instructions to help you to operate and repair your truck

Covered models:
HT25Ds
HT30Ds

Format: PDF, 146 Pages, Printable
Language: English

Contents:

0. Product information
   1283 truck series
   The truck
1. ENGINE
   DIESEL TYPE
   TECHNICAL ENGINE DATA
   Technical engine data
   Special service tools
   EXPLANATION OF THE ENGINE SERIAL NUMBER
   Explanation of the engine serial number
   CHECKING AND SETTING OF THE VALVE CLEARANC
   Valve clearance measurement
   Valve clearance adjustment
   Removal of Timing Gears
   Removal oftiming gears
   Installation of Timing Gears
   Installation oftiming gears
   Check and Adjust Cooling FanV-belt
   Check and adjust cooling fan V-belt
   CYLINDER HEAD
   Removal of cylinder head
   Assembly of cylinder head
   INJECTION NOZZLES
   Defective injection nozzles
   Removal offuel injection pupm
   Inspection and testing of the fuel injectors
   FUEL INJECTION PUMP
   Removal offuel injection pupm
   Installation of the fuel injection pupm
   CHECKING/ADJUSTMENTOFFUELINJECTIONTIMING
   Checking/adjustment offuel injection timing
2. TRANSMISSION
   TRANSMISSION TXL30/ST
   TECHNICAL DATA
   TECHNICAL DATA
   Circuitry
   CIRCUITRY
   Kinematic diagram of the transmission
   KINEMATIC DIAGRAM OF THE TRANSMISSION
   General description
   General description
   TXL 30 /ST General views
   TXL 30/ST General section
   TRANSMISSION HYDRAULIC SYSTEM -SUPERMODULATING DISTRIBUTOR ..
   Transmission hydraulic system -supermodulating distributor
   Hydraulic diagram - Supermodulating Distributor
   Scheme A of hydraulic diagram-Gear in neutral position-Supermodulating Distrib ...
   Scheme B of hydraulic diagram-Reverse gear,started lift ruck-Supermodulating Distrib
   Scheme C of hydraulic diagram-Inching reverse gear-Supermodulating Distrib.
   DISASSEMBLING AND RE-ASSEMBLING OF TRANSMISSION
   - GENERAL INST
   RUCTIONS
   General instructions
   GENERAL INSTRUCTIONS /Storage and service instructions
   DISASSEMBLING AND RE-ASSEMBLING OF TRANSMISSION - Specific tools
   Dismantle and assemble transmission
   Converter case overhauling
   Dismantling and re-assembling of Supermodulating Distributor
   Wheel hubs dismantling and re-assembling - IstVersion
   Shoes setting procedure
   Wheel re-assembling - IstVersion
   Brake reassembly
   Wheel hubs reassembling
   Dismantling and re-assembling wheel hubs-Brakes(2nd Version)
   Bearings adjustment specifications
   Dismantle transmission
   Clutches overhauling
   Differential overhauling
   Differential reassembly and bevel gear set positioning with relevant adjustment ...
   Bevel pinion-and-ring gear set inspection
   Control inching - assy
   DATA FOR COUPLING TO ENGINE
   Data for coupling to engine
   Engine with P. T. O. coupling diagram
   Engine gearbox coupling check-up
   Technical data - Supermodulating Distributor pressure measu rement
   RUNNING-IN
   RUNNING-IN
   TROUBLESHOOTING PROCEDURE
   Troubleshooting procedure
   Common running faults in all gears
   Running faults with gears engaged
   Further problems
   Bad working in idle
   Transmission overheating
   Process instruction to couple transmission to engine
   PROCESS INSTRUCTION TO COUPLE TRANSMISSION TO ENGINE

Annex
6. Electrics / Electronics
   General
   Wiring diagram
   Circuit diagrams without ISO 3691
   Circuit diagrams with ISO 3691
   Traction, working and steering hydraulics
