Practical Amplifier Diagrams by Jack Robin & Chester Lipman (1947)

"Practical Amplifier Diagrams" by Jack Robin and Chester E. Lipman (1947, 104 pages).

This book contains 45 proven circuits for the technician and experimenter.

CONTENTS

PART 1 – Schematic Drawings and Explanatory Notes

1 Tube 1 Watt AC/DC Amplifier
1 Tube AC/DC “Wireless” Phonograph Oscillator
2 Tube 1-1/2 Watt AC/DC Amplifier
2 Tube Contact Microphone Amplifier
2 Tube 4 Watt AC Booster Amplifier (“Transformerless”)
2 Tube 5 Watt AC Booster Amplifier
2 Tube Battery Intercommunication Amplifier
2 Tube AC/DC Intercommunication Amplifier
3 Tube 2 Watt Economy AC/DC Amplifier
3 Tube 3 Watt Direct Coupled Amplifier
3 Tube 4 Watt AC Amplifier
3 Tube 4 Watt AC “Transformerless” Amplifier
3 Tube 8 Watt AC Amplifier
3 Tube Quick Heating AC Intercommunication Amplifier
3 Tube 1-1/2 Watt AC/DC Intercommunication Amplifier
3 Tube Hearing Aid Battery Amplifier
4 Tube 5 Watt AC/DC Amplifier
4 Tube 5 Watt AC/Bat P.A. Amplifier
4 Tube 6 Watt AC High-Fidelity Amplifier (High Gain)
4 Tube 6 Watt AC High-Fidelity Amplifier
4 Tube 6 Watt AC Home Recording Amplifier
4 Tube 10 Watt AC High-Fidelity Amplifier
4 Tube 15 Watt AC Low Gain Amplifier
4 Tube 3 Channel Preamplifier
5 Tube 10 Watt Class – B 6 Volt DC Amplifier
5 Tube 13 Watt AC High-Fidelity Amplifier
5 Tube 13 Watt AC High-Fidelity P.A. Amplifier
5 Tube 15 Watt Quick Heating Phonograph Amplifier
5 Tube 35 Watt Transmitter Amplifier
5 Tube 30 Watt AC P.A. High-Fidelity Amplifier
6 Tube 6 Watt AC 2 Channel Amplifier
6 Tube 10 Watt 6 Volt DC P.A. Amplifier
6 Tube 10 WattAC P.A. High-Fidelity Amplifier
6 Tube 12 Watt AC Recording and Playback Amplifier
6 Tube 25 Watt AC High-Fidelity P.A. Amplifier
6 Tube 45 Watt AC Fixed Bias Amplifier
7 Tube 14 Watt Recording and Playback Amplifier
7 Tube 20 Watt AC High-Fidelity Amplifier
7 Tube 45 Watt AC P.A. Amplifier
8 Tube 12 Watt AC Phonograph Expander & Compressor Amplifier
8 Tube 25 Watt AC 4 Channel P.A. Amplifier
8 Tube 50 Watt AC Transmitting Modulator
9 Tube 45 Watt AC P.A. Amplifier
10 Tube 15 Watt Compact AC P.A. Amplifier
11 Tube 75 Watt AC P.A. Amplifier

PART 2 – Servicing Your Amplifier

The original book was scanned and converted into this digital book in Adobe Acrobat .pdf format.  In order to view this file you will need to have Adobe Acrobat Reader installed on your computer.
