Komatsu 94E,98E Series Diesel Engine Workshop Service Repair Manual

Go ahead to take this service manual.Please contact to us if with any problems..
This manual can be used by anyone from a first time owner/amateur to a professional technician.Easy to read type,And give you all the information needed to do the procedure correctly.Keep this shop manual handy and use it often. Performing routine,preventive maintenance will save you time & money by helping to prevent premature failure and unnecessary repairs.

******************************
Models andĀ Applicable Machine :

4D94E-1A ENGINE:
Machine model Machine Serial No.
D20P-7 78604 and up
D20P-7 62454 and up
D20PL-7 62454 and up
D20PLL-7 62454 and up
D20QG-7 62454 and up

4D98E-1A ENGINE:
Machine model Machine Serial No.
D21A-7T 78604 and up

*****************
Manual Contents:

Specifications and performance
Cross sectional views
Cooling water, lubricating oil and fuel oil
Troubleshooting
Special service tools and measuring instruments
Measurement, inspection and adjustment
Measuring procedures, service data and corrective action
Disassembly and reassembly
Service data
Tightening torque
Fuel injection pump for indirect injection system
Fuel injection pump for direct injection system
Governor
Turbocharger
Service information for carb ulg regulation
Attached drawing
Epa certified engine

*****************
File Format: PDF
Compatible: All Versions of Windows & Mac
Language: English
Requirements: Adobe PDF Reader
