Amplifier Builder's Guide by the Editors of Radio Craft - Hi-Fi Tube Amp Info

“Amplifier Builder's Guide” by the Editors of Radio Craft (1947, 65 pages). This practical guide concentrates on the design and construction of audio amplifiers. Two parts: the first on amplifier theory and design, the second giving six practical designs to build. Talks about phase splitters, feedback, and tone controls, things not addressed in most textbooks.

Part One
- Frequency Response
- Internal Feedback Problems
- Phase Inversion
- Resonant Tone Controls
- Equalizing the Pickup
- Volume Expanders
- Decibel Level vs Gain
- A Decibel Nomograph

Part Two
- An 8-Watt PA System
- 16-Watt FM Amplifier
- 10 Watts - Direct Coupled
- Transformer-Coupled 6L6's
- Wire-Recorder & Amplifier
- Dual High-Fidelity System

In order to view this file you will need to have Adobe Acrobat Reader installed on your computer.
