Linde Order Picker Type 1111: N20VI, N20VLI Service Training (Workshop) Manual

Original Illustrated Factory Service Training (Workshop) Manual for Linde Order Picker Type 1111.

Original factory manuals for Linde Forklift Trucks, contains high quality images, circuit diagrams and instructions to help you to operate and repair your truck

Covered models:
N20VI
N20VLI

Format: PDF, 196 Pages
Language: English

Contents:

0. Product information
   Description
   Order picker N20VI-VLI type 1111
   Diagnostics
   Accessing truckinformation
   Can Bus Network
   Multi-function indicator, breakdown code display
   Breakdown code descriptions
   TRACTION fault codes
   LIFT fault codes
   Fault codes -STEERING -Main Controller
   Fault codes -STEERING -Safety Controller
1. Engine
   Traction motor
   Description
   Removing the drive motor
   Traction motor bearing
2. Drive - Transmission
   Drive unit
   Description of the drive unit
   Removal/replacement of the drive unit
   Fitting the drive unit to the chassis
   Reducer
   Gear reducer
   Reducer unit
   Removal / refitting reducer gearbox
3. Truck structure
   Driver's platform
   Description
   Removing the dashboard
   Removing the platform backrest
   Mounting the driver's platform
4. Steering, braking and wheels
   Electrical steering
   General
   Control handlebar
   Removing the handlebar
   Steering centre (LORD)
   Steering geared motor
   Removal/replacement of the steering motoreducer
   Wheel position potentiometer (3B3)
   Steering motor (3M1)
   Electric steering adjustment
   Brake
   Hydraulically assisted electromagnetic parking brake
   Wheels
   Rolling base
   Drivewheel
   Suspended stabiliser wheel
   Support rollers
6. Electrical equipment
   N20VI/N20VLI type 1111
   General
   Location of platform connectors and controls
   Operation of the N20 VI and N20 VLI type 1111 order pickers
   Electrical panel
   Manipulating the electrical plate
   Fuse access
   Traction (L.A.C. 03)
   Tractionandhydrauliccontroller-LAC03/1A1
   Functions of the "Inputs/ Outputs" of the LAC 03
   Turning on the LAC Controller- 1A1
   Replacing the L.A.C. box (1 A1)
   Setting up the control module (1A1)
   Accelerator (1S21, 1 S22) and potentiometer (1B1) controls
   Horn4H1
   Hydraulically assisted electromagnetic brake Y1
   Traction motor speed sensor 1 B2
   Monitoring traction motor temperature 1B6
   Battery locking sensor 1S1 9
   Controlling the LAC cooling fan 9M1
   Speed restriction n°1 and n°2 (options)
   Hydraulic controls
   Controlling platform detectors 2B6, 2B7 and 2B9
   Controlling Initial Lift detectorsl B3 and 1 B4
   Controlling mast detectors (N20 VLI)2B1 and 2B6
   Platform height detectors 2B7.2B8 and 2B9
   Initial Lift height detector 1 B4 and 1 B3
   Fork height detectors 2B1 and 2B6(N20VLI)
   Hydraulics functions
   Mast hydraulic pressure
   Initial Lift operation
   Electrical steering (L.E.S. 40
   Electric steering controller L.E.S./3A1
   Functions of the "Inputs/ Outputs," LES(3A1)
   Replacing the L.E.S. box (3A1)
   Setting steering control module parameters (3A1 )
   LES Controller power up
   Speed reduction when turning (with LAC n°390 360 85 19)
   Multifunction display (Bauser)
   4-button multifunction indicator (version CAN BUS)
   Programming the multifunction indicator
   Changing the multifunction display
   Replacing the key (S1) with a DIGICODE
7. Hydraulic assembly
   Hydraulic equipment
   N20VI and N20VLI configurations
   Description of the pump unit
   N20 VI & N20 VLI: installation and tightening torques of pump unit components
   Platform / mast selection block (N20 VLI)
   Replacing the motor pump brushes
   Working on the pump unit
8. Lifting system
   Initial Lift
   Fork carriage

Annex
10. Diagrams
   Circuit diagrams
   Power
   N20 VI controls
   N20VLI controls
   Hydraulic diagrams
   N20 VI type 1111
   N20VLI type 1111
