Ham and CB Antenna Dimension Charts - For Builders

"Ham and CB Antenna Dimension Charts" by Edward M. Noll (1970, 66 pages).

From the Preface:
The charts in this book tabulate dimension information in feet and inches for all the popular antenna configurations. These charts have been subdivided in such a manner that an antenna can be dimensioned for a specific frequency range according to license class and mode of operation (cw, phone, or ssb). Dimensions can be obtained for a specific band and application, very quickly, without making any calculations. The dimensions have been developed from standard and accepted classic equations, although several equations were worked out experimentally by the author.

The charts contain fourteen main categories as shown in the Contents. Each category comprises eight to eleven individual charts. Each chart, in turn is subdivided into bands and specific frequencies according to mode of operation (phone or cw) and frequency spectrum assigned to specific license grades (novice, technician, general, advanced, and extra).

In each category dimensions are given based on the band-center frequency, center of the cw spectrum, and center of the phone spectrum. Dimensions are also given for optimum operation in the novice bands or the various segments assigned specifically to those operators with advanced or extra license grades. This information is first given in a group comprising the 15-, 20-, 40-, and 80-meter bands. Because of differing frequency assignments and popular operating procedures, individual charts are given for the 2-, 6-, 10- and 160-meter bands.

· Dipole Dimension Charts
· Quarter-Wave Verticals
· Antenna Element Spacings
· Coaxial Phasing Lines (0.66 VF)
· Coaxial Phasing Lines (0.81 VF)
· Two-Element Beams with Reflector
· Two-Element Beams with Director
· Three-Element Beams
· Five-Element Beams
· Two-Element Quads
· Two-Element Triangles
· Inverted Dipoles
· Inverted-Vee Long Wires (120 degrees)
· Dimension Charts at Work
· Equation Table

The original book was scanned at a resolution of 300 dpi and converted into this digital book in Adobe Acrobat .pdf format.

In order to view this file you will need to have Adobe Acrobat Reader installed on your computer.
