Grabby (1.0.4)

Grabby is a set of tools that help you select entities in more precise ways.



Tools Overview:





EdgeGrab
uses your mouse as a brush to select edges.


  • Click & hold the mouse button.

  • Hover over the edge entity you want to add to the selection.

  • If you hold SHIFT key it will deselect edge.

  • Press Esc key to exit tool once you're happy with your selection.


See Example
https://s20.postimg.cc/ozm0f2u25/Edge_Grab.gif




FaceGrab uses your mouse as a brush to select faces.


  • Click & hold the mouse button.

  • Hover over the face entity you want to add to the selection.

  • If you hold SHIFT key it will deselect face.

  • Press Esc key to exit tool once you're happy with your selection.


See Example
https://s20.postimg.cc/dyqvalzel/Face_Grab.gif




ExpandGrab expands the selection by one more polygon.

See Example
https://s20.postimg.cc/bg569wy8t/Expand_Grab.gif




ShrinkGrab shrinks the selection by one more polygon.

See Example
https://s20.postimg.cc/53q0zknbh/Shrink_Grab.gif




LoopGrab selects edges that form a loop.


  • First, select a single edge for connecting loop.

  • Make sure the edge is part of a quad face.

  • Activate the tool...

  • And, if all went according to plan the loop should be selected.


See Example
https://s20.postimg.cc/h85agk07h/Loop_Grab.gif



Forums



Installing on SketchUp 2017 & 2018

Inside SketchUp, select Window → Extension Manager (Microsoft Windows) or SketchUp → Extension Manager (Mac OS X), then click → Install Extension and select the RBZ file you just downloaded. Voila! SketchUp installs the extension.



Installing on SketchUp 2016

Inside SketchUp, select Window → Preferences (Microsoft Windows) or SketchUp → Preferences (Mac OS X) → Extensions → Install Extension and select the RBZ file you just downloaded. Voila! SketchUp installs the extension.
