Assignment 1 Solution

1.    ) Write a program to create a pgm le with 8x8 checkerboard pattern. Image dimensions will be 800x800 pixels and each black and white cell will be 100x100 pixels. Consider the following gure for details. In the gure B denotes black cells and W denotes white cells.



800





100       100                                 100





100     B          W      W



100          W





800











100          W      B







Figure 1: Checkerboard



PGM     le format is as follows



P2



Width Height



MaxGray



Data



Width and height are width and height of the image. MaxGray is the maximum gray value. This will be 255 in our case. Data is grayscale pixel values (0 for black, 255 for white) separated by space. When your program produces the pgm les, you can use gpicview or gimp to open pgm les on machines running Linux. Use pgm extension for your les.





Sample pgm     le is given below



P2



7   5



255



255 255 255 255 255 255 255



200 200 200 200 200 200 200



150 150 150 150 150 150 150



100 100 100 100 100 100 100



50 50 50 50 50 50 50



Submit your program electronically using the blackboard system



The program you submit should be your own work. Cheating will be reported to office of academic integrity.



Both the copier and copiee will be held responsible.
