Programming II Integer set 1

 Assignment: Create three sets from lists of integers found in files i061.dat, i062.dat,
and i063.dat. Find set I the intersection of set 1 and set 2. Find set U the
union of set 2 and set 3. Find set D the difference of set U - set I. Print
results in file o06.dat as shown in Figure 2.
Prohibition: Use of the C++ Standard Template Library is prohibited in the
implementation of this project.
Program Files: Project 6 consists of files p06.cpp, List06.h, Set06.h, and p06make.
Project file names are exactly as given. Failure to employ the foregoing
names will result in a score of zero (0) for this project
Project files must be stored in the root directory of your student account.
Failure to store project files in the root directory of your student account
will result in a score of zero (0) for this project.
File Description
p06.cpp File p06.cpp contains functions that process command line
arguments and direct set operations.
List06.h File List06.h contains all that is required for template
<class T class List { … }; Class List implements a list of
integers by dynamically allocating individual elements of a
list. Each element contains an element of type T. Elements
are placed in a doubly linked circular list with a sentinel
after the element containing the largest value. Elements
are stored in ascending order. Elements are dynamically
allocated when needed and discarded after they are no
longer required. Elements of the list are unique.
Class List is the base class.
Set06.h File Set06.h contains all that is required for template
<class T class Set : public List { … };. Class Set is derived
from class List. Set operations include insertion, deletion,
union, intersection, and difference, and printing.
p06make File p06make contains instructions for creating executable
file p06. Instructions in file p06make are accepted by the
UNIX utility make.

Command Line: Project 6 can be invoked with up to four program parameters. The first
three program parameters are the names of the input files containing sets
1, 2 and 3. The fourth program parameter in the name of the output file
where results are recorded. Sample command lines together with
corresponding actions by program p06 are shown below. Boldfaced type
indicates data entered at the keyboard by the user.
$ p06
Enter the name of input file 1: i061.dat
Enter the name of input file 2: i062.dat
Enter the name of input file 3: i063.dat
Enter the output file name: o06.dat
$ p06 i061.dat
Enter the name of input file 2: i062.dat
Enter the name of input file 3: i063.dat
Enter the output file name: o06.dat
$ p06 i061.dat i062.dat
Enter the name of input file 3: i063.dat
Enter the output file name: o06.dat
$ p06 i061.dat i062.dat i063.dat
Enter the output file name: o06.dat
$ p06 i061.dat i062.dat i063.dat o06.dat
Input files: Input files contain a list of integers. Unique integers in the list are the
elements of a set. Sample data is given in below.
Input file 1: 1 2 3 4
Input file 2: 2 4 6 8
Input file 3: 1 3 5 7
Output files: The format of the output file is shown in Figure 2. Data shown in Figure 2
is produced by Program p06 given input files shown above.
Figure 2.
Output file format: set 1={1,2,3,4}
set 2={2,4,6,8}
set 3={1,3,5,7}
set I={2,4}
set U={1,2,3,4,5,6,7,8}
set D={1,3,5,6,7,8}
