T5 WC & STD On-Vehicle Service and Troubleshooting

T5 WC & STD On-Vehicle Service and Troubleshooting

T5 WC & STD On-Vehicle Service and Troubleshooting PDF. This manual contains maintenance, service and parts information for the T5 Five-Speed Manual Transmission manufactured by TREMEC.
Applications:
1982-83 AMC Spirit
1982-83 AMC Concord
1982-88 AMC Eagle
1982-86 Jeep CJ-7
1984-86 Ford Mustang SVO (World-Class T-5 1985-1986)
1983-1995 V8 Ford Mustang (World-Class T-5 1985-1995)
1983-1986 V8 Mercury Capri (World-Class T-5 1985-1986)
1994-2010 V6 Ford Mustang
1983-1993 Inline-4 Ford Mustang
1983-1986 Inline-4 Mercury Capri
1983-1988 Ford Thunderbird Turbo Coupe and Mercury Cougar XR-7
1986-2004 Ford Falcon
1985-1987 Ford Sierra RS Cosworth
1988 Ford Sierra RS500 Cosworth
1988-1989 Ford Sierra Cosworth Sapphire 2wd
Chevrolet S-10 Blazer
1983-1992 Chevrolet Camaro (World-Class T-5 with RPO code MK6)
1993-2002 Chevrolet Camaro (V6 models World-Class)
1986-1990 Chevrolet Astro
1986-1990 GMC Safari
1993-1995 Chevrolet S-10
1982-1986 Jeep CJ-7 and Jeep CJ-8 Scrambler (optional)
1983-1986 Mercury Cougar XR-7
1982-1983 (Datsun) Nissan 280ZX Turbo
1984-1986 Nissan 300ZX Turbo
1989-1995 Holden Commodore VN – VS S1
Panther Solo 2
1983-1992 Pontiac Firebird (World-Class T-5 with RPO code MK6)
1993-2002 Pontiac Firebird (V6 models World-Class)
Ssangyong Musso
Ssangyong Korando
TVR Griffith 500
TVR Chimaera 500
TVR Cerbera
TVR Tuscan with the option of a close ratio gearset on 1st, 2nd & 3rd gears for the Tuscan S
TVR T350
TVR Tamora
TVR Sagaris with the option of the close ratio gearset used in the Tuscan S
CONTENTS:
INTRODUCTION AND DESCRIPTION
Introduction
Description
T5 WC & STD ON-VEHICLE SERVICE AND TROUBLESHOOTING
Maintenance
Troubleshooting
Transmission Removal
Transmission Installation
T5 WC DISASSEMBLY
General Information
T5 HD Transmission Disassembly Procedures
T5 STD DISASSEMBLY
General Information
T5 STD Transmission Disassembly Procedures
T5 WC & STD CLEANING, INSPECTION, REPAIR OR REPLACEMENT
Cleaning
Inspection
Repair or Replacement
T5 WC ASSEMBLY
General Information
T5 HD Transmission Assembly Procedures
T5 STD ASSEMBLY
General Information
T5 STD Transmission Assembly Procedures
Language: English
Format: PDF
Pages: 79
Size: 1.94 Mb
