Panasonic Lumix DMC-FH24 FH25 FS35
Digital Camera Service Manual & Repair Guide
CONTENTS:
1 Safety Precaution
1.1. General Guidelines
1.2. Leakage Current Cold Check
1.3. Leakage Current Hot Check (See Figure 1.)
1.4. How to Discharge the Capacitor on Flash
PCB
2 Warning
2.1. Prevention of Electrostatic Discharge (ES
to Electro statically Sensitive (ES) Devices
2.2. How to Recycle the Lithium Ion Battery
2.3. Caution for AC Cord(For EB/GC/SG)
2.4. How to Replace the Lithium Battery
3 Service Navigation
3.1. Introduction
3.2. General Description About Lead Free Solder
3.3. Important Notice
3.4. How to Define the Model Suffix
4 Specifications
5 Location of Controls and Components
6 Service Mode
6.1. Error Code Memory Function
6.2. ICS (Indication of additional Camera Settings
when picture was taken) function
7 Service Fixture & Tools
7.1. Service Fixture and Tools
7.2. When Replacing the Main P.C.B.
7.3. Service Position
8 Disassembly and Assembly Instructions
8.1. Disassembly Flow Chart
8.2. P.C.B. Location
8.3. Disassembly Procedure
8.4. Disassembly Procedure for the Lens
8.5. Assembly Procedure for the Lens
8.6. Removal of the CCD Unit
8.7. Removal of the Focus Motor
8.8. The Application of Grease Method
9 Measurements and Adjustments
9.1. Introduction
9.2. Before Disassembling the unit
9.3. Details of Electrical Adjustment
9.4. After Adjustment
10 Maintenance
10.1. Cleaning Lens and LCD Panel
This manual covers the following models:
DMC-FS35EB
DMC-FS35EE
DMC-FS35EF
DMC-FS35EG
DMC-FS35EP
DMC-FH25P
DMC-FH25PC
DMC-FH25PR
DMC-FH25PU
DMC-FH25GA
DMC-FH25GC
DMC-FH25GF
DMC-FH25GH
DMC-FH25GK
DMC-FH25GN
DMC-FH25GT
DMC-FH24P
Pages total: 68
Language: English
Format: PDF
