Komatsu Crawler Dozers D31EX-21, D31PX-21, D37EX-21, D37PX-21 Workshop Service Manual

Original Illustrated Factory Workshop Service Manual for Komatsu Crawler Dozers D31, D37.
Original factory manuals for Komatsu Loaders, Dozers, Excavators contains high quality images, circuit diagrams and instructions to help you to operate, maintenance and repair your truck. All Manuals Printable, contains Searchable Text and Navigation Bookmarks

Covered models:
    D31EX-21 50001 and up
    D31PX-21 50001 and up
    D37EX-21 5001 and up
    D37PX-21 5001 and up

Format: PDF, 407 Pages
Language: English

Contents:
     GENERAL
         SPECIFICATION DRAWING
         SPECIFICATIONS
         WEIGHT TABLE
         TABLE OF FUEL, COOLANT AND LUBRICANTS
     STRUCTURE AND FUNCTION,  MAINTENANCE STANDARD
         COOLING SYSTEM
         ENGINE CONTROL
         POWER TRAIN
         POWER TRAIN SYSTEM
         HST HYDRAULIC EQUIPMENT ARRANGEMENT DIAGRAM
         STEERING, BRAKE CONTROL
         DAMPER
         SOLENOID VALVE
         FINAL DRIVE
         HST PUMP
         SAFETY-SUCTION VALVE
         CUT-OFF VALVE
         CHARGE SAFETY VALVE
         CHARGE PUMP
         HST BRAKE QUICK RETURN CIRCUIT
         TOWING VALVE
         PARKING BRAKE VALVE
         AS VALVE
         HST MOTOR
         STEERING, DIRECTIONAL PPC VALVE
         INCHING VALVE
         AUTOMATIC GEARSHIFTING VALVE
         FRAME ASSEMBLY
         TRACK FRAME, RECOIL SPRING
         IDLER
         TRACK ROLLER
         CARRIER ROLLER
         SPROCKET
         TRACK SHOE
         ARRANGEMENT OF HYDRAULIC EQUIPMENT FOR WORK
         EQUIPMENT
         WORK EQUIPMENT CONTROL
         HYDRAULIC TANK, FILTER
         HYDRAULIC PUMP
         WORK EQUIPMENT CYLINDER
         CONTROL VALVE
         CLSS
         WORK EQUIPMENT PPC VALVE
         WORK EQUIPMENT
         CUTTING EDGE, END BIT
         CAB RELATED
         SAFETY MECHANISM WHEN STARTING ENGINE
         GEARSHIFT CONTROL SYSTEM
         PARKING BRAKE CONTROL SYSTEM
         COMPONENT EQUIPMENT OF SYSTEM
         MONITOR SYSTEM
         SENSORS .
     TESTING AND ADJUSTING
         STANDARD VALUE TABLE
             STANDARD VALUE TABLE FOR ENGINE
             STANDARD VALUE TABLE FOR CHASSIS
             STANDARD VALUE TABLE FOR ELECTRICAL SYSTEM
         TESTING AND ADJUSTING
         TROUBLESHOOTING
     DISASSEMBLY AND ASSEMBLY
     OTHERS
         HYDRAULIC CIRCUIT DIAGRAM (1/2)
         D31EX-21 Serial No50001 – 50097
         D31PX-21 Serial No50001 – 50181
         D37EX-21 Serial No5001 – 5104
         D37PX-21 Serial No5001 – 5090
         HYDRAULIC CIRCUIT DIAGRAM (1/2)
         D31EX-21 Serial No50098 and up
         D31PX-21 Serial No50182 and up
         D37EX-21 Serial No5105 and up
         D37PX-21 Serial No5091 and up
         HYDRAULIC CIRCUIT DIAGRAM (2/2)
         HYDRAULIC CIRCUIT DIAGRAM (2/2) (For D37EX, PX-21 EU spec.)
         ELECTRICAL CIRCUIT DIAGRAM (1/2)
         ELECTRICAL CIRCUIT DIAGRAM (2/2)
         ELECTRICAL CIRCUIT DIAGRAM FOR AIR CONDITIONER .
