Jungheinrich Truck ETB230/340, ETR225/230/230D/230DP/235/340/340P/345/345P Service Manual

Original Illustrated Factory Workshop Service Manual for Jungheinrich Electric Reach Truck Type ETR, ETB.

Original factory manuals for Jungheinrich Forklift Trucks, contains high quality images, circuit diagrams and instructions to help you to operate and repair your truck. All Manuals Printable and contains Searchable Text

Covered models:
    ETB230 (01.2010-05.2014)
    ETB340 (01.2010-05.2014)
    ETR225D (01.2010-05.2014)
    ETR230 (01.2010-05.2014)
    ETR230D (01.2010-05.2014)
    ETR230DP (01.2010-05.2014)
    ETR235 (01.2010-05.2014)
    ETR340 (01.2010-05.2014)
    ETR340P (01.2010-05.2014)
    ETR345 (01.2010-05.2014)
    ETR345P (01.2010-05.2014)

Language: English
Format: ZIP, Contained Set of PDF Manuals:
1. Operating manual, PDF, 85 Pages
2. Service Manual, PDF, 381 Pages
    Contents:
        MAST INSTALLATION INSTRUCTIONS
        GENERAL INFORMATION & FEATURES
            Glossary
            Reach Truck Serial Number Definition
            General Overview
            Jacking Truck
            Load Wheel Replacement Guide
            Caster Adjustment
            Brake Assembly Inspection and Adjustmen
            Adjustment of Air Gap with Brake Applied
            Friction Disc Replacement
            Transmission
        THEORY OF OPERATIONS
            Solenoid Activation Chart
            Main Hydraulic Manifold
            Theory of Operation
        OPERATOR DISPLAY
        OPERATOR DISPLAY INFORMATION & PROGRAMMING
        MAST
        HYDRAULIC SCHEMATICS
            Legend
            Standard Performance with Tilt
            Standard Performance with Tilt and Sideshift
            High Performance with Tilt
            High Performance with Tilt and Sideshift
        CONTROLLER
        TROUBLESHOOTING FOR CONTROL CIRCUITS
        PLANNED MAINTENANCE
            Maintenance Locations
            Maintenance Intervals
            Service Data
