Mercury Mercruiser #22 Engine IN-LINE Diesel D2.8L D-Tronic, D4.2L D-Tronic Service Manual 1997-UP

Mercury Mercruiser #22 Marine Engine IN-LINE Diesel D2.8L D-Tronic, D4.2L D-Tronic Workshop Service Repair Manual 1997-UP
Go ahead to take this service manual. Please contact to us if with any problems..
This manual can be used by anyone from a first time owner/amateur to a professional technician. Easy to read type, And give you all the information needed to do the procedure correctly. Keep this shop manual handy and use it often. Performing routine, preventive maintenance will save you time & money by helping to prevent premature failure and unnecessary repairs.

*****************************

Models Covered:

Sterndrive (MCM) - Serial Number
D2.8L D-Tronic - S/N: 0K000001 and Above
D4.2L D-Tronic - S/N: 0K000001 and Above

Inboard (MIE)
D2.8L D-Tronic - S/N: 0K000001 and Above
D4.2L D-Tronic - S/N: 0K000001 and Above

**********************************************

TABLE OF CONTENTS:

SECTION 1 - IMPORTANT INFORMATION
A - General Information
B - Maintenance
C - Troubleshooting

SECTION 2 - REMOVAL AND INSTALLATION
A - Sterndrive (MCM) Models
B - Inboard (MIE) Models

SECTION 3 - ENGINE MECHANICAL
A - D2.8L D-Tronic And D4.2L D-Tronic Engines

SECTION 4 - ELECTRICAL SYSTEM
A - Starting System
B - Charging System
C - Glow Plug System (If Equipped)
D - Instrumentation
E - Wiring Diagrams

SECTION 5 - FUEL SYSTEM
A - Description
B - Fuel Delivery Pump and Fuel Filter
C - Injectors
D - Injection Pump
E - EDI Diagnosis

SECTION 6 - COOLING SYSTEM
A - Seawater Cooling System
B - Closed Cooling System

SECTION 7 - INTAKE AND EXHAUST SYSTEM
A - Intercooler
B - Intake / Exhaust Manifold, Elbows and Risers
C - Turbocharger

SECTION 8 - DRIVE SYSTEM
A - ZF / Hurth Transmissions
B - Propeller Shaft Models

SECTION 9 - POWER STEERING SYSTEM
A - Pump And Related Components

*****************
File Format: PDF
Compatible: All Versions of Windows & Mac
Language: English
Requirements: Adobe PDF Reader
