Linde Truck H-Series Type 313: C80/3, C80/4, C80/5, C80/6 Service Training (Workshop) Manual

Original Illustrated Factory Service Training (Workshop) Manual for Linde IC Engined Truck H-Series Type 313.

Original factory manuals for Linde Forklift Trucks, contains high quality images, circuit diagrams and instructions to help you to operate and repair your truck

Covered models:
C80/3
C80/4
C80/5
C80/6

Format: ZIP, Icnluded:
C80 Series 313 Service Training, PDF, 35 Pages
H 100/120/136/150/160, Type 354 Service Training, PDF, 227 Pages

Language: English

Contents:
1 Drive engine
       See H 100/120/136/150/160, Type 354
2 Hydrodynamic travel drive
       See H 100/120/136/150/160, Type 354
3 Truck body
       See H 100/120/136/150/160, Type 354
4 Steering system
       See H 100/120/136/150/160, Type 354
5 Air braking system
       See H 100/120/136/150/160, Type 354
6 Electrical system
       See H 100/120/136/150/160, Type 354
7 Hydraulic system
   7.1 Hydraulic circuit diagram
   7.1.1 Functional description of working hydraulics
   7.2 Control schematic
   7.2.1 Functional description of control
   7.3 Routing of working hydraulics hoses
   7.4 Routing of oil suction and return hoses
8 Lift mast
   8.1 Installation of mast and spreader
   8.2 Adjusting the angle of tilt
   8.3 Lift cylinder
   8.3.1 Sealing the lift cylinder
   8.4 Tilt cylinder
   8.4.1 Sealing the tilt cylinder
   8.5 Spreader
   8.5.1 Valve block and hydraulic circuit diagram of spreader
   8.5.2 Circuit diagram Spreader
