Linde Electric Tractor Type 131: P50 Service Training (Workshop) Manual

Original Illustrated Factory Service Training (Workshop) Manual for Linde Electric Tractor Type 131.

Original factory manuals for Linde Forklift Trucks, contains high quality images, circuit diagrams and instructions to help you to operate and repair your truck

Covered models:
P50

Format: PDF, 135 Pages
Language: English

Contents:

0. Product information
   Description
   P50 Tractor, Type 131
   Diagnostics
   Accessing truck information
   Can Bus Network
   Multi-function indicator, breakdown code display
   Breakdown code descriptions
   TRACTION breakdown codes ( LAC 03)
   Breakdown codes STEERING Primary Controller (LES 40)
   Breakdown codes STEERING Safety Controller (LES 40)
1. Engine
   Traction motor
   Description
   Removing the drive motor
2. Drive - Transmission
   Drive unit
   Description of the drive unit
   Removal/replacement of the drive unit
   Gear reducer
   Gear reducer
   Reducer unit
   Removal /Replacement of reducer
3. Truck structure
   Battery compartment
   Battery compartment
   Battery removed from the side
   Access to the technical compartment
   Technical compartment covers
   Chassis equipment
   Tow coupling
4. Steering, braking and wheels
   Electric steering
   Electric steering
   Control tiller, AP
   Dismantling the AP tiller arm
   Replacement of the tiller stops
   Adjustment ofthe tiller foot pull switches, 1S4 and 1S4-A
   Steering centre (LORD)
   Steering motoreducer
   Removal/replacement ofthe steering motoreducer
   Wheel position potentiometer (3B3)
   Steering motor (3M1)
   Electric steering adjustment
   Brake
   Electromagnetic parking brake without hydraulic assistance
   Wheels
   Wheelbase
   Drivewheel
   Suspended stabiliser wheel
   Load wheels
6. Electrical equipment
   P50 Type 131
   General
   Truck operation: P50Type 131
   Connector location
   Electrical panel
   Manipulating the electrical plate
   Fuse access
   Traction (L.A.C. 03)
   Tractionandhydrauliccontroller-LAC03/1A1
   Functions ofthe "Inputs /Outputs" ofthe LAC 03
   Turning on the LAC Controller- 1A1
   Replacing the L.A.C. box (1A1)
   Setting up the control module (1A1)
   Accelerator (1S21, 1 S22) and potentiometer (1B1) controls
   Horn 4H1
   Electromagnetic brake Y1 (without hydraulic assistance)
   Traction motor speed sensor 1 B2
   Monitoring traction motor temperature 1B6
   Battery locking sensor 1S1 9
   Controlling the LAC cooling fan 9M1
   Speed restriction n°1 and n°2 (options)
   Electrical steering (L.E.S. 40)
   Electric steering controller L.E.S./3A1
   Functions of the "Inputs/ Outputs," LES(3A1)
   Replacing the L.E.S. box (3A1)
   Setting steering control module parameters (3A1 )
   LES Controller power up
   Speed reduction during turns
   Multifunction display (Bauser)
   4-button multifunction indicator (version CAN BUS)
   Programming the multifunction indicator
   Replacing the multifunction indicator
   Using PathFinderto set multifunction indicator parameters
   Replacing the key (S1) with a DIGICODE

Annex
10 Diagrams
   Circuit diagrams
   Power
   Control:
