Linde Electric Lift Truck 386 EX Series: E14 EX, E16 EX, E18 EX, E20 EX Workshop Service Manual

Original Illustrated Factory Workshop Service Manual for Linde Electric Lift Truck 386 EX Series.

Original factory manuals for Linde Forklift Trucks, contains high quality images, circuit diagrams and instructions to help you to operate and repair your truck

Covered models:
    E14 EX
    E16 EX
    E18 EX
    E20 EX

Format: PDF, 102 Pages
Language: English

Contents:
    1 Drive
        Traction motor
        Description
        Removal and installation
    3 Chassis, bodywork and fittings
        Driver's compartment
        Driver's seat — leak resistance
    4 Chassis frame
        Tyres
        Checking tyres for leak resistance
    5 Operating devices
        Display and operating devices
        Display and operating devices
    6 Electrical system
        Electrical controller
        Electrical components in the additional electrical installation housing
        Electrical components in the contactor housing
        Electrical components in the control housing
        Zener barriers — intrinsic safety
        Insulation monitoring
        Description
        Temperature switch
        X13 — Pin assignment
        Testing the insulation resistance of the electrical system
        Clock circuit
        Connections
        Connections — axle
        Connections — display unit
        Connections — contactor housing
        Connections — control housing
        Connections — intrinsically safe control housing
        Terminal strip assignment
        Terminal strip X1 — control housing
        Terminal strip X2 — control housing
        Terminal strip X3 — contactor housing
    Annex
    10 Circuit diagrams
        Wiring diagram
        Basic equipment for E14-20 Ex (II 2G IIBT4) part 1/5
        Basic equipment for E14-20 Ex (II 2G IIBT4) part 2/5
        Basic equipment for E14-20 Ex (II 2G IIBT4) part 3/5
        Basic equipment for E14-20 Ex (II 2G IIBT4) part 4/5
        Additional electrical installation for E14-20 Ex (II 2G IIBT4) part 5/5
