TROUBLESHOOTING YOUR OSCILLOSCOPE - Tektronix

TROUBLESHOOTING YOUR OSCILLOSCOPE - GETTING DOWN TO BASICS” (94 pages).

TABLE OF CONTENTS

Chapter 1 - TROUBLESHOOTING TECHNIQUES AND PROCEDURES

Chapter 2 - TROUBLESHOOTING YOUR OSCILLOSCOPE
Front Panel Diagnosis
Isolating the Faulty Section
The Basic Oscilloscope
The Power Supply
The Vertical Section
The Horizontal Section
Portable Oscilloscope Tips and Techniques
Microprocessor Based Portable Oscilloscope Tips and Techniques
Lab Instrument Oscilloscope Techniques

Chapter 3 - TROUBLESHOOTING THE POWER SUPPLY
Checking Power Supply Regulation
Resistance Measurements
Transistor Supplies
Common Power Supply Problems

Chapter 4 - TROUBLESHOOTING THE HIGH-EFFICIENCY POWER SUPPLY
The High-Efficiency Power Supply
Guidelines for Troubleshooting the High-Efficiency Supply
Typical High-Efficiency Supply Problems

Chapter 5 - TROUBLESHOOTING THE CRT AND Z-AXIS SECTION
The High Voltage Supplies
Typical High voltage Problems
CRT Conditions

Chapter 6 - TROUBLESHOOTING THE VERTICAL SECTION
Isolating Faulty Preamplifiers
Isolating Faults in the Verticals Laboratory Oscilloscopes
Troubleshooting Tips for the Vertical Section
Common Mode Operation
Tracking Down a Noisy Circuit

Chapter 7 - TROUBLESHOOTING THE HORIZONTAL SECTION
Isolating the Horizontal Amplifier
Lab Instruments Oscilloscope Tips and Techniques
Typical Horizontal Problems
Isolating Faults in the Time Base
Timebase Sequence
Tips for Troubleshooting Trigger Circuits
Tunnel Diode Triggering
Trigger Operation
Tips for Troubleshooting the Sweep Circuits
Typical Sweep Problems

The original book was scanned and converted into this digital book in Adobe Acrobat .pdf format.  In order to view this file you will need to have Adobe Acrobat Reader installed on your computer.
